Ai -30°C 17L Recirculating Chiller with 20L/Min Centrifugal Pump

$6,290.00

Categories: , SKU: C30-17-10L

Description

Ai C30 series recirculating chillers are the true thermostatic control laboratory chiller, these closed laboratory chillers are ideal for applications such as cooling rotary evaporators, analytical instrumentation, laser etching, ICP, vacuum systems, plasma etching and jacketed reactors. This system can also be used as a replacement to tap water cooling in laboratory applications.

Ai C30 are compressor-based recirculating chillers that offer outstanding performance and high reliability as well as quiet operation and ease-of-use. Powerful force/suction pump provides constant flow rates, while microprocessor PID controller gives you the ideal solution when you need precise temperature control or cooling below ambient temperature.

IMPORTANT! -30°C/-22°F ULTIMATE TEMPERATURES ARE TESTED UNDER EMPTY LOAD CONDITION (NO ROTARY EVAPORATORS OR JACKETED REACTORS ATTACHED).

C30 circulating chiller features

  • ETL tested to UL and CSA standards
  • No dry ice or liquid nitrogen needed
  • Advanced PID digital temp controller
  • Built-in chilling fluid filter protects the recirculating pump and prevent blockage
  • All steel construction for durability
  • Eco-friendly R410A refrigerant
  • Cost saving as the water consumption is completely eliminated
  • Built-in casters for mobility
  • Insulated tubing included
  • Recommended for 10L rotary evaporators

Specifications



 Model  C30-17-10L
 Temperature range  Ambient to -30°C (No load)
 Electrical requirements  220V 60Hz 1-PH, 1200 watts (Not compatible with 50Hz power)
 Cooling capacity
(Assuming working environment
25°C/77°F)
 @ 32°F/0°C:          1,750W
@ 14°F/-10°C:       1,100W
@-4°F/-20°C:           700W
@-22°F/-30°C:         300W
 Compressor  Make: Panasonic
Power: 208-230V 60Hz 1-PH
Number of compressor: one
Refrigerant: R410A
 Recirculating pump  Type: Centrifugal
Output: 100 watts
Pumping speed: 20 L/min or 5.3 gallon/min
Maximum head: 20 feet or 6 meter
Maximum pressure: 5.8 psi
 Coolant outlet pressure  Displayed on the built-in mechanical pressure gauge
 Reservoir  Material: Type 304 stainless steel, polished
Chilling fluid connection: 3/8″ hose barb x 2
Capacity: 17 liters or 4.5 gallons
 Temperature controller  Type: Digital microprocessor PID controlled
Display unit: Celsius °C
Temperature accuracy: +/- 2°C
Temperature range: Ambient to -30°C
 Temperature sensor type  Pt100
 Housing  Powder coated type 42 stainless steel
 Recommended coolant  For 50°F/10°C or higher:
distilled water
Between 50°F/10°C and -22°F/-30°C:
50% ethylene glycol + 50% distilled water
 Working environment  -15°C/5°F to 25°C/77°F, at <66% humidity
 Built-in swivel casters  Four
 Unit/shipping dimensions  26.5 x 18 x 30.5″ / 32 x 23 x 40″ (WxDxH)
 Unit/shipping weight  175 Lbs / 235 Lbs
 Safety  Compressor over-temp protection
Compressor delay start protection
Short circuit and ground protection
Over-current protection
 Recommended for rotary evaporators  Ai 10L SolventVap rotary evaporators
 Warranty  One year
 Compliance  UL 61010-1 :2012 Ed.3+R:29Apr2016
CSA C22.2#61010-1 :2012 Ed.3



Additional information

Weight 270 lbs
Dimensions 30 × 30 × 30 in
